SMK BLVD Digital Leaf Wetness Sensor


SMK BLVD Digital Leaf Wetness Sensor

Specifications

Measuring Range temperature-20~80℃
Wetness 0~100%
Response time <1s , Accuracy: ±1℃(25℃);±5%(25℃)
Output RS485 modbus procotol
Power supply DC9~24V , Working current1:7mA(DC12V)
Power consumption DC12V <=0.22W
Cable Length 3M
Ingress protection IP65

Brief Introduction

The SMKBLWD Leaf wetness sensor is an important tool for observing and studying leaf wetness, preventing pests and diseases, and spraying sprinkler control. The accurate measurement of the moisture content of the leaf surface can be used to monitor the trace moisture or ice crystal residue. The shape of the sensor is simulated by the blade, which can simulate the characteristics of the leaf surface, so that it can reflect the situation of the leaf surface more accurately. By measuring the variation of the dielectric constant of the upper surface of the blade, the mist, water vapor and ice can be measured.
